600W 78000lm ATEX Zone 1 Zone 2 Explosion Proof LED Flood Light for Hazardous Areas
Produktdetails:
| Herkunftsort: | Guangdong, China |
| Markenname: | Fins board, BOCAQ |
| Zertifizierung: | CE,ROHS,FCC,PSE,CCC,ATEX, ISO9001,BSCI |
| Modellnummer: | EPFL-600W-Z1 |
Zahlung und Versand AGB:
| Min Bestellmenge: | 10 Stk |
|---|---|
| Preis: | Verhandlungsfähig |
| Verpackung Informationen: | Packung + Blase oder nach Maß |
| Lieferzeit: | 10-15 Tage oder bestätigen |
| Zahlungsbedingungen: | T/T, Western Union |
| Versorgungsmaterial-Fähigkeit: | 5000 Stück/Monat |
|
Detailinformationen |
|||
| Leistung: | 600W | Lichtstrom: | 78000lm |
|---|---|---|---|
| Wirksamkeit: | 130lm/W | Farbtemperatur: | 5000K (Kaltweiß) |
| Abstrahlwinkel: | 120° | Eingangsspannung: | Wechselstrom 100–277 V, 50/60 Hz |
| LED-Chip: | Bridgelux SMD 3030 | IP-Bewertung: | IP66 |
| Gehäusematerial: | ADC12 aus Aluminiumdruckguss | Linsenmaterial: | Gehärtetes Glas 5 mm |
| Betriebstemperatur: | -40°C bis +60°C | Montagemöglichkeiten: | Verstellbare Halterung, Mastmontage, Deckenmontage |
| Zertifizierung: | ATEX II 2G Ex d IIC T6 Gb | Lebensdauer: | ≥50.000 Stunden L70 |
| Garantie: | 5 Jahre | ||
| Hervorheben: | 600W Explosion Proof Light,ATEX Zone 1 LED Floodlight,Hazardous Area Industrial Lighting |
||
Produkt-Beschreibung
The EPFL-600W-Z1 is a high-power 600W explosion proof LED flood light engineered for demanding industrial environments requiring ATEX Zone 1 and Zone 2 certification. With an outstanding 78000lm luminous output and 130lm/W efficacy, this floodlight delivers exceptional illumination while maintaining the strictest safety standards for hazardous locations. A direct replacement for traditional 2000W HID/HPS floodlights with over 65% energy savings.
- 600W High Power Output - 78000lm total luminous flux with 130lm/W efficacy, replacing 2000W HID equivalents
- ATEX Certified - ATEX II 2G Ex d IIC T6 Gb for Zone 1, Zone 2 gas and Zone 21, Zone 22 dust atmospheres
- Robust Die-Cast Aluminum Housing - ADC12 aluminum alloy with anti-corrosion powder coating for long-term outdoor durability
- IP66 Weatherproof - Fully sealed against dust ingress and powerful water jets, suitable for the harshest environments
- 5mm Tempered Glass Lens - High-transmittance glass with IK08 impact resistance rating
- Bridgelux SMD 3030 LEDs - Premium LED chips delivering stable 5000K cool white light
- Wide 120° Beam Angle - Optimal light distribution for large-area coverage in refineries, chemical plants, and offshore platforms
- Universal Voltage Input - AC 100-277V 50/60Hz compatible with global electrical systems
- Multiple Mounting Options - Adjustable bracket, pole mount, and ceiling mount configurations included
- 5-Year Warranty - Backed by ≥50,000 hours L70 lifespan testing
Ideal for ATEX Zone 1 and Zone 2 classified areas including:
- Oil refineries and petrochemical processing plants
- Offshore drilling platforms and FPSO vessels
- Chemical storage warehouses and mixing facilities
- Gas compressor stations and LNG terminals
- Paint spray booths and solvent handling areas
- Grain silos and flour mills (dust explosive atmospheres)
- Coal mining preparation plants
| Model Number | EPFL-600W-Z1 |
|---|---|
| Power Consumption | 600W |
| Luminous Flux | 78000lm |
| Efficacy | 130lm/W |
| Color Temperature | 5000K (Cool White) |
| Beam Angle | 120° |
| Input Voltage | AC 100-277V 50/60Hz |
| LED Chip | Bridgelux SMD 3030 |
| IP Rating | IP66 |
| Housing Material | Die-Cast Aluminum ADC12 |
| Lens | Tempered Glass 5mm |
| Operating Temperature | -40°C to +60°C |
| Mounting | Adjustable Bracket / Pole Mount / Ceiling Mount |
| Certification | ATEX II 2G Ex d IIC T6 Gb |
| Lifespan | ≥50,000 Hours L70 |
| Warranty | 5 Years |
As a leading manufacturer of hazardous area lighting solutions, ECER delivers explosion proof LED flood lights that combine cutting-edge LED technology with rigorous safety engineering. The EPFL-600W-Z1 is our flagship high-power model, designed for applications demanding maximum lumen output in ATEX classified environments. Each unit undergoes 100% factory testing including pressure testing of the explosion-proof enclosure and photometric verification.
For bulk orders, OEM/ODM customization, or technical inquiries, please contact our sales team.
